The V12 series IP65 waterproof push button switch has an electrical rating of 2A, 36VDC and has an electrical life expectancy of 200,000 cycles. Multiple actuator finish options are available, including a black anodized finish.
These long-life IP65 switches come with single-pole circuits and screw or solder lug termination options.
They are meant for mounting in a panel cutout sized 12mm in diameter.[/vc_column_text][vc_column_text]
- IP65 rated protection against dust and moisture
- Solder lug or screw terminal options available
- 1 pole; momentary pushbuttons
[/vc_column_text][vc_column_text]Applications for this anti-vandal switch include:[/vc_column_text][vc_column_text]
- Kiosks and ticket dispensers
- Industrial controls
- Medical equipment
- Electrical housewares
- Audio/visual
- Security devices
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_single_image image=”8922″ img_size=”full” alignment=”center”][vc_custom_heading text=”Brochure” font_container=”tag:h3|font_size:18|text_align:center|color:%23f19901″ use_theme_fonts=”yes” link=”url:https%3A%2F%2Fwww.langir.com%2Fwp-content%2Fuploads%2F2019%2F04%2Fv12-anti-vandal-switch.pdf|title:Brochure|target:_blank”][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]
Functions
[/vc_column_text][vc_column_text]
[/vc_column_text][vc_row_inner][vc_column_inner][vc_column_text]
Order Code
[/vc_column_text][vc_column_text]
[/vc_column_text][/vc_column_inner][/vc_row_inner][vc_column_text]
Technical Data
[/vc_column_text][vc_column_text]
| Type | V12-B-S | V12-B-N | V12-B-A | |
| Actuator Options | Round | |||
| Function | Momentary 1no | |||
| Specification | 0.6kgs/box | |||
| Number of Switch | Single Control Switch | |||
| Certification | ISO9001, CE, CCC, RoHS, Reach | |||
| Usage | Control Button, Start Button, Reset Button, Control Switch | |||
| Max. Panel Thickness: | 0.236″ (6.0mm) | |||
| Terminal | Screw / Solder lug (2.8 x 0.5) | |||
| Max. Switch Rating | 2A/ 48VDC | |||
| Contact Resistance | ≤50mΩ | |||
| Insulation Resistance | ≥1000mΩ | |||
| Dielectric Strengh | 2000VAC | |||
| Operation Temp. | -20°C ~ +55°C | |||
| Transport Package | 50PCS/Box | |||
| Mechanical Life | >1,000,000cycles | |||
| Electrical Life | >200,000cycles | |||
| Torque | 5 ~ 14Nm | |||
| Operation Pressure | ~3.5N | |||
| Operating Stroke | ~2.5mm | |||
| Protection | IP65 | |||
| Material | Contact | Silver Alloy | ||
| Actuator | Stainless Steel/ Brass/ PBT | |||
| Body | Stainless steel | Nickel plated brass | Zin-Al Alloy | |
| Base | PBT | |||
| Color | Actuator |       |
||
[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]
Descriptions/ Panel Cutout
[/vc_column_text][vc_column_text]
[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]
Dimension
[/vc_column_text][vc_column_text]
[/vc_column_text][vc_column_text]
Solder terminal
[/vc_column_text][vc_column_text]
[/vc_column_text][vc_column_text]
Screw terminal
[/vc_column_text][vc_separator][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]
FAQs
[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]Q1: Is the V12 IP65 waterproof switch suitable for industrial control panels?
A: Absolutely, the V12’s durability and protection against water and dust make it a reliable choice for use in industrial control panels, ensuring dependable operation in challenging environments.
Q2: Can the V12 IP65 switch be used in outdoor security systems?
A: Yes, the V12 waterproof push button switch is well-suited for outdoor security applications, providing reliable control in outdoor surveillance setups.
Q3: Does Langir offer different color options for the IP65 waterproof switch?
A: Langir may provide various color choices for the IP65 switch, allowing you to select a color that suits your application’s aesthetic requirements.
Q4: What materials are used in the construction of the V12 IP65 waterproof push button switch?
A: The V12 switch is likely constructed from durable and corrosion-resistant materials, ensuring longevity even in challenging conditions. Refer to Langir’s specifications for precise details.
Q5: Can the V12 switch handle continuous operation?
A: The V12 waterproof switch is designed for dependable operation, but it’s essential to consider the specific application’s requirements and the switch’s duty cycle.
Q6: Is the IP65 waterproof push button switch easy to clean?
A: Yes, the IP65 waterproof push button switch’s design likely allows for easy cleaning, making it suitable for environments where cleanliness is crucial, such as food processing or medical applications.
Q7: Can the V12 switch be used in outdoor marine applications?
A: While the V12 switch is waterproof, it’s essential to consider the specific marine environment. For saltwater exposure, you may want to consult Langir’s experts for guidance on the appropriate marine-grade switches.
Q8: What is the expected lifespan of the IP65 waterproof push button switch?
A: The IP65 waterproof push button switch’s durability and construction are likely designed for a long lifespan. However, factors such as usage, environmental conditions, and maintenance can impact the switch’s longevity.
Q9: Can the V12 switch be operated with gloves?
A: Depending on the specific design of the V12 switch, it may be possible to operate it with gloves, making it suitable for applications where users wear protective gear.
Q10: Is the IP65 waterproof push button switch suitable for medical equipment?
A: The V12’s waterproof and dustproof design makes it a potential option for certain medical equipment, particularly when cleanliness and reliability are essential.[/vc_column_text][vc_zigzag]
